Grass Grid

APPLICATIONS

Permanent soil reinforcement.

A perfect alternative to Paving Blocks, Concrete, or Asphalt.

It is most commonly used on roads and car parks, but the measure can also apply to a broader use of permeable areas to promote greater infiltration.

The Alwasail Green grass/gravel grids are very strong and preserve the natural landscape of developed areas. The grid systems are intended for soil reinforcement along circulation routes that need uniform, stable, and naturally permeable paving.

Applications List:

Residential housing and hotel grass and gravel parking lots.
Access and fire roads.
Slope revetment and pond shore stabilization.
Camping grounds and golf courses.
Tramway trackbed.
Pedestrian and bike lanes.
Green features in parks, gardens, and residential projects.
Outdoor gym areas.
Garage driveways, garden paths, and house perimeter drainage.

Model	ALWASAIL Grass Grid
product size	50050050mm
product weight	~962.5g
material is HDPE	HDPE
thickness is	2.5mm
AXLE LOAD (KN)	140
GREEN AREA RATIO	96%
COLOUR	green; black
FIRE ROADS	yes
CLASSIFICATION	16/16 DIN1072
REINFORCEMENT SPIKES	integrated
MARKERS	yes
FILLING	soil; stones

ECOLOGICAL AND DURABLE

Alwasail Green products are made of 100% recycled plastic.

We use granulated PP and PE recycled on-site. This input is made exclusively from clean production waste that is free from heavy metals and other contaminants. All Alwasail Green products are recyclable for sustained environmental protection.

Our ecological systems find applications in surface reinforcement as a natural alternative to concrete products.

Green Areas

Alwasail Green products conform to EU requirements and regulations for green areas. The openwork structure of the grids permits unhindered vegetation and the growth of plants.

We Build Water-Permeable Surfaces

The unique design of the stabilization system ensures almost 100% retention of rainwater. The grids filled with grass or aggregate keep the soil drainage unobstructed to prevent flooding.
