- Available in 1″, 1/2″ and 2″ sizes, NPT or BSP threads.
- 1″ available with female thread or socket inlet/outlet.
- Virgin PVC material construction (NSF approved material).
- Internal manual bleed lever standard on all valves.
- Heavy-duty diaphragm.
- Manual bleed can be removed for a “tamper-proof” operation.
- Flow range from 5 to 120 GPM
- 1 1/2″ and 2″ provided with both bottom (angle) or side inlet.
- All stainless steel fasteners and components.
- Standard 24 VAC 60 Hz solenoid (black wire) Hex plunger design for sandy weather conditions.
- Special 24 VAC 60 Hz solenoid for European and Australian power (white wire).
- 1″ available with or without a flow control system.
- 1 1/2″ and 2″ standard with flow control stem.
- Operating pressure ranges from 10 PSI to 150 PSI.
- Suitable for residential and commercial applications.
Operation Specifications:
- 1″ Flow: 5-30 GPM / 3-115 l/min
- 1 1/2″ Flow: 5-80 GPM / 18-305 l/min
- 2″ Flow: 5-120 GPM 18-455 l/min
- Operating pressure: 15 to 150 PSI / 1 to 10, 3 bars; 103 to 1035 kPa
- Recommended velocity not to exceed 5 fbs
Electrical
- 24 VAC standard
- Inrush: 350 mA
- Holding: 250 mA
- Cycles: (white wires) 50 Hz or (black wires) 60 Hz
Features
- Internal manual bleed
- Stainless steel components
- PVC construction
- Plug provided for unused inlet (1 1/2″ and 2″)
- Recommended velocity not to exceed 5 fbs
Options Available:
- Reclaimed purple valves (consult price list)
- 110 VAC solenoid
- BSP threads
For more information, the datasheet can be downloaded on this link.
